- General Information
- Manufacturer
- Schneider Electric SA
- Manufacturer Website Address
- http://www.schneider-electric.com.au
- Brand Name
- APC by Schneider Electric
- Product Line
- EasyPDU
- Packaged Quantity
- 1 / Pack
- Product Type
- PDU
- Technical Information
- PDU Type
- Switched
- Phase
- Three Phase
- Plug/Connector Type
- IEC 60309 32A 3P+N+PE
- Receptacle Type
- IEC 60320 C13
- IEC 60320 C19
- Receptacle Detail
- 30 x IEC 60320 C13
- 6 x IEC 60320 C19
- Features
- LCD Display
- Load Capacity (VA)
- 22.08 kW
- Load Capacity (Watt)
- 22 kW
- Power Description
- Input Voltage
- 400 V AC
- 230 V AC
- Input Voltage Range
- 200 V AC - 240 V AC
- 346 V AC - 415 V AC
- Output Voltage
- 230 V AC
- Input Current
- 32 A
- Input Frequency
- 60 Hz
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Mounting Orientation
- Vertical
- Mounting Preference
- No Preference
- Mount Type
- Rack-mountable
- Form Factor
- Rack
- Rack Height
- 0U
- Height
- 1800 mm
- Width
- 56 mm
- Depth
- 62 mm
- Weight (Approximate)
- 8.75 kg
- Environmental Conditions
- Minimum Operating Temperature
- -5°C
- Maximum Operating Temperature
- 50°C
- Minimum Storage Temperature
- -25°C
- Maximum Storage Temperature
- 65°C
- Miscellaneous
- Application/Usage
- Data Center
- IT Equipment
