Linear Barcode Plus QR Code Scanner
The DuraScan D820 is a linear barcode & QR Code 1D/2D barcode reader with Bluetooth wireless technology. It reads the most popular 2D/1D barcodes and is perfect for retail point of sale, inventory management, sales order entry, field service, and other mobile business applications. Users can scan barcodes printed on labels or displayed on screens. Designed for mobility, durability and lasting up to two shifts. The external rubberized material increases drop protection. Easy to use and attachable to a mobile device, enabling one-handed operation, it slips neatly into your pocket and fits comfortably in the palm of your hand.
- General Information
- Manufacturer
- Socket Mobile, Inc
- Manufacturer Website Address
- http://www.socketmobile.com
- Brand Name
- Socket Mobile
- Product Line
- DuraScan
- Product Type
- Barcode Scanner
- Warranty
- Limited Warranty
- 1 Year
- Technical Information
- Connectivity Technology
- Wireless
- Scanning Capability
- 1D
- 2D
- Barcode Symbology Supported
- 1D:
- Codabar
- Code 39
- Code 93
- Code 128
- EAN-13
- EAN-8
- Interleaved 2 of 5
- ISBT 128
- UPC A
- UPC E1
- Chinese 2 of 5
- Codabar
- Code 11
- Code 16KCode 39
- Code 93
- Code 128
- Discrete 2 of 5
- EAN-13
- EAN-8
- GS1 Databar
- Industrial 2 of 5
- Interleaved 2 of 5
- Matrix 2 of 5
- MSI Plessey
- UPC A
- UPC E1
- Standard 2 of 5
- UK Plessey
- Data Matrix
- Micro QR Code
- PDF417
- QR Code
- Aztec
- Data Matrix
- Han Xin
- Micro PDF417
- Micro QR Code
- PDF417
- QR Code
- Image Sensor Type
- Linear
- Scan Pattern
- Omni-directional
- Linear
- Scanning Distance
- 381 mm
- Field of View (Horizontal)
- 45°
- Field of View (Vertical)
- 34°
- Maximum Ambient Light
- 100000 lux
- Drop Specification
- Multiple 6.5 ft. (2 m) drops to concrete
- Minimum Print Contrast
- 25%
- Maximum Element Resolution (Code 39)
- 0.13 mm
- Maximum Element Resolution (DataMatrix)
- 0.25 mm
- Network & Communication
- Bluetooth
- Yes
- Battery Information
- Battery Included
- Yes
- Battery Weight
- 12.5 g
- Physical Characteristics
- Weight (Approximate)
- 71.4 g
- Miscellaneous
- Package Contents
- DuraScan D820 - 1D/2D Linear Barcode Plus QR Code Scanner
- Klip
- Charging Dock
- USB Charging Cable
- 1 year limited Warranty on DuraScan and charging dock
- Compatibility
- Apple - iPod , iPhone , iPad
- Ingress Protection (IP) Rating
- IP40
- Application/Usage
- Inventory
- Transportation
- Warehouse
- Field Sales/Service
- Commercial Service
- Hospitality
- Logistics
- Healthcare
- Platform Supported
- Mac
- PC
- Android
